Hikvision DS-2CE16D0T-LPXTS

Specification

• Camera
• Image Sensor2 MP CMOS
• Max. Resolution1920 (H) × 1080 (V)
• Min. Illumination0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/12.5 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0° to 360°,Tilt: 0° to 90°,Rotate: 0° to 360°
• Signal SystemPAL/NTSC
• Lens
• Lens Type2.8 mm, 3.6 mm fixed lens
• Focal Length & FOV
• 2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°
• 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°
• Lens MountM12
• Microphone
• Pickup DistanceIn a radius of up to 5 m
• Amount1
• Speaker
• Rated Power2 W
• Speaker RangeIn a radius of up to 5 m
• Illuminator
• Supplement Light TypeSmart,IR,White Light
• Supplement Light RangeIR: Up to 25 m,White Light: Up to 20 m
• Image
• Image Settings
• Anti-banding,
• Brightness,
• Sharpness,
• Smart IR
• Frame RateTVI: 1080p @25 fps/30 fps
• Day/Night ModeAuto/Color
• Wide Dynamic Range (WDR)Digital WDR
• Image Enhancement
• DWDR,
• BLC,
• HLC,
• Global,
• HLS
• Noise Reduction3D DNR
• White Balance
• Auto,
• Manual
• Audio
• Audio FunctionEcho Cancellation, AI Noise Reduction, Automatic Gain Control
• Interface
• Video Output1 HD analog output
• AlarmFlashing Light Alarm (Red & Blue)
• General
• Power12 VDC ± 25%, max.6.5 W,*You are recommended to use one power adapter to supply the power for one camera.
• MaterialPlastic
• Dimension179 mm × 66 mm × 69.1 mm (7.05″ × 2.6″ × 2.72″)
• Approx. 265 g (0.58 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish
• Approval
• ProtectionIP67
