MERCUSYS MB115-4G
300 Mbps Wireless N 4G LTE Router
- 4G network – Share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps
- Plug a SIM card and play – No configurations needed, compatibility of SIM cards are assured by years of field tests*
- 300 Mbps WiFi – Fast WiFi speeds up to 300 Mbps to share your network.
-
Maximum Network Coverage – Enjoy stable and efficient connections to every device thanks to the four external antennas
- Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can’t get a 4G connection
Description
- Wireless Standards
- IEEE 802.11b/g/n
- Frequency
- 2.4 GHz
- Signal Rate
- 300 Mbps
- Reception Sensitivity
- 11g 54M: -74.5 dBm11n HT20 MCS7: -73.5 dBm11n HT40 MCS7: -70.5 dBm
- Transmission Power
-
- < 20 dBm (2.4 GHz)
- Wireless Security
- WPA-PSK / WPA2-PSK
- Wireless Functions
- Enable/Disable Wireless Radio, Wireless Schedule, WMM, WirelessStatistics
- Software
- DHCP
- Server
- Hardware
- Dimensions (W X D X H)
- 219 × 140 × 32 mm
(8.62 × 5.51 × 1.26 in)
- Interfaces
- 1× 10/100Mbps LAN/WAN Port
3× 10/100Mbps LAN Ports
1× Nano SIM Card Slot
- Button
- WPS、Reset Button
- Ethernet Ports
- 1× 10/100 Mbps LAN/WAN Port +
3× 10/100 Mbps LAN Ports
- Network Type
- EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
CN:
FDD-LTE: B1/B3/B5/B8 (2100/1800/850/900 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
- Others
- Package Contents
- 300 Mbps Wireless N 4G LTE Router (MB115-4G)
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
- Environment
- Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40°F~140°F)
Operating Humidity: 10%~90% Non-Condensing
Storage Humidity: 5%~90% Non-Condensing
