DS-1LN6U-G
305 m CAT6 UTP Network Cable (Solid Copper, 0.55 mm, Gray)
- Full diameter 305 m CAT6 network cable
- Core diameter: 0.55mm
- Excellent transmission performance using solid copper
- Quality verified by Fluke test
- Guaranteed long PoE transmission distance
- Great PVC flame resistance.
Description
- Accessories
- CategoryCat.6
- Steath printingHIKVISION 4PR 23AWG 75℃ U/UTP CAT6 VERIFIED TO ANSI/TIA-568-C.2 PVC ****m mm/dd/yyyy Tracing Code-HS
- Reference standardISO/IEC11801,ANSI/TIA-568-C.2,RoHS 2.0
- Fire resistanceNo
- ConductorSolid-Bare Copper (99.95%);0.55±0.005 mm，23 AWG
- InsulationHDPE;0.98±0.05 mm
- Rip-cordYes
- SeparatorYes
- Sheath physical properties
- Before agingTensile strength ≥ 13.5 Mpa;Elongation ≥ 150%
- Aging period100 ℃ Ă— 24h Ă— 10d
- After agingTensile strength ≥ 12.5Mpa;Elongation ≥ 125%
- Cold bend-20 ± 2℃ Ă— 4h，8 Ă— cable O.D,no visible cracks
- Electrical Characteristics(20℃)
- 1.0-250.0 MHz impedance100 ± 15Ω @ ≤ 100MHz；100 ± 25Ω @ 100-250MHz
- 1.0-250.0 Mhz delay skew≤ 45 ns/100 m
- DC resistance≤ 9.38 Ω/100 m
- DC conductor resistance unbalance≤ 5.0 %
- Package dimension400 mm (W) Ă— 400 mm (H) Ă— 240 mm (D)(15.75″ Ă— 15.75″ Ă— 9.45″)
- 12.3 ± 0.5kg
- Cable length(305 ±1.5) m
- Ambient temperature-20 ℃ to 75 ℃ (-4℉ to 167℉)
- Operating voltage60 V
- Sheath
- Thickness0.5±0.10 mm
- MaterialPVC
- ColorGrey
- Diameter6.00±0.30 mm
